This Jenn-Air® Trifecta™ Dishwasher with 46 dBA delivers brilliant results while working quietly and saving energy. The Sensor Wash Cycle automatically chooses the correct cycle for consistently impeccable cleaning.
$0.00
Specifications
General
Type
Built-In
Color
Stainless Steel
Place Settings
15
Tub Material
Stainless Steel
Silence Rating
46 dB
Cycle Information
Number of Cycles
5
Wash Cycles
Sensor Wash Cycle with ClearScan™ Turbidity Sensor.
One Hour Wash Cycle.
China/Crystal Cycle
Heavy Wash Cycle.
Normal Wash Cycle.
SuperScrub Option.
Precision Dry™ Option.
Sanitize Option.
Features
Delay Start Information
13 Hours
Delay Start
Yes
Control Lock
Yes
Additional Information
4 Light Item Clips (Upper Rack).
2-Position Fold-Away™ Tines (Lower Rack).
2 Nylon Racks with Ball-Tip Tines.
Custom Upper Racking System with Premium Ajusters.
2 Wire Cup Shelves with Integrated Stemware Holders (Upper Rack).
2 Fold-Down Rows with Adjustable Tines (Lower Rack)
Silverware Basket with Three Covers.
TriFecta™ Wash System.
Dual Wattage Heating Element.
Sensor Fill System.
Waterlock™ Flood Protection Technology.
Electrical Information
Information
120
Certifications and Approvals
Energy Star Certified
Yes
Dimensions
Class Width
24"
Width
23.5 inch(es) / 59.69 cm
Height (Min.)
30.04 inch(es) / 76.3 cm
Depth (Without Handle)
25.63 inch(es) / 65.09 cm
Depth (Including Handle)
27.87 inch(es) / 70.8 cm
Additional Dimensions
Door width: 23 1/2" - 59.7 cm; Toe kick width: 23 1/2": - 59.6 cm; Top of handle height: 29 1/8" - 73.9 cm; Door height: 30" - 76.3 cm; Adjustable toe kick height (min.): 3 1/"2-41/8" - 8.9-10.5 cm; Recessed dishwasher width: 23 3/4" - 60.4 cm; Depth with tub flange: 22 5/8" - 57.4 cm; Depth with door: 24 5/8" - 62.6 cm; Depth with handle Pro-Style stainless: 27 7/8" - 70.8 cm, Euro-Style (color-coordinating): 26 7/8" - 68.3 cm; Depth with door fully open: 49 3/4" - 126.3 cm;
Shipping Dimensions
Width
24.75 inch(es) / 62.87 cm
Height
35.63 inch(es) / 90.49 cm
Depth
26.5 inch(es) / 67.31 cm
Weight
95 lb(s) / 43.09 kg
Warranty
Warranty
Limited 1-year parts and labor.
In the second through the fifth year from the date of purchase, when your major appliance is installed, operated and maintained according to instructions attached to or furnished with the product, Jenn-Air will pay for factory specified parts for the following components if defective in materials or workmanship: dish racks, all parts of the wash system, drain motor, electronic controls and heating element. Replacements parts will also be provided if there is rust including the exterior cabinet and front panels.
For the lifetime of the product from the date of purchase, when this major appliance is installed, operated and maintained according to instructions attached to or furnished with the product, Jenn-Air will pay for factory specified parts and repair labor for the following components to correct defects in materials or workmanship that existed when this major appliance was purchased: stainless steel tub
and inner door liner.
UPC
UPC#
883049247656
