This Fisher & Paykel 24-inch double DishDrawer™ dishwasher allows you to wash one drawer and stack the other or wash both at once using different programs. This model features SmartDrive™ technology, 15 wash programs, a delay start up to 12 hours and can accommodate up to 14 place settings (7 per drawer).
$0.00
Specifications
General
Type
Built-In
Color
Black Stainless
Manufacturer Color
Black Stainless Steel
Place Settings
14
Silence Rating
44 dB
Cycle Information
Number of Cycles
15
Wash Cycles
• Delicate
• Extra Dry
• Fast
• Heavy
• Medium
• Normal Eco
• Quick
• Rinse
• Sanitize
• 3 Wash Modifiers
• Extra Dry
• Fast
• Heavy
• Medium
• Normal Eco
• Quick
• Rinse
• Sanitize
• 3 Wash Modifiers
Features
Technologies
SmartDrive™ Technology
Delay Start Information
Up to 12
Delay Start
Yes
3rd Rack System
No
Control Lock
Yes
Silverware Basket
Yes
Wi-Fi
No
Additional Information
• Place Settings: 14 (7 Per Drawer)
• 2 Cutlery Basket
• Quiet Operation
• Flow Through Detergent Dispenser
• End Of Cycle Beeps
• Electronic Fault/diagnostic Indicator
• Rinse Aid Indicator Light
• Maximum Plate Height 12.25" (Upper Drawer) And 11" (Bottom Drawer)
• Fan-assist Dry
• Water Consumption: 3.28 Gal Running Both Tubs
• Automatic Child Lock Once Started
• 2 Cutlery Basket
• Quiet Operation
• Flow Through Detergent Dispenser
• End Of Cycle Beeps
• Electronic Fault/diagnostic Indicator
• Rinse Aid Indicator Light
• Maximum Plate Height 12.25" (Upper Drawer) And 11" (Bottom Drawer)
• Fan-assist Dry
• Water Consumption: 3.28 Gal Running Both Tubs
• Automatic Child Lock Once Started
Electrical Information
Information
• 263 kWh/y
• 120 V
• 60 Hez
• 15 A
• 120 V
• 60 Hez
• 15 A
Certifications and Approvals
Energy Star Certified
Yes
Accessories
Included
• Kick Strip
• Knife Clip and Multipurpose Clip
• Knife Clip and Multipurpose Clip
Dimensions
Class Width
24"
Width
23.58 inch(es) / 59.9 cm
Height (Min.)
34.02 inch(es) / 86.4 cm
Depth (Without Handle)
22.58 inch(es) / 57.35 cm
Warranty
Warranty
Limited 2 years parts and labor
UPC
UPC#
822843818341
Features
SMARTDRIVE™ WASH FUNCTION
The unique brushless DC motor acts as both a wash pump and a drain pump, which means less moving parts and greater reliability. The pump brings water into the spray arm, which rotates at different speeds depending on the wash cycle selected to deliver a superior clean and better dish care.
SANITIZE CLEAN & DRY
Selecting `Sanitize’ will raise the temperature of the final rinse to a temperature that will sanitize your dishes and baby bottles. The ‘Extra Dry’ setting improves the drying result even on plastic dishes.
INDEPENDENT DRAWERS
An independent drawer based dishwashing platform is part of what makes DishDrawer™ dishwasher unique. At bench height drawers glide open for easy access, visibility and better ergonomics. In Double DishDrawer™ dishwashers both drawers operate independently so different wash cycles can operate simultaneously to accommodate a variety of loads. Glasses, pots and pans can be washed in separate drawers at the same time.
QUICK, SANITISE AND EXTRA DRY OPTIONS
The 'Quick' wash modifier delivers a faster wash while maintaining performance.The ‘Sanitise’ option provides extra protection killing 99.9% of bacteria in the final rinse. The ‘Extra Dry’ setting is perfect for plastic dishes.
HOW DISHDRAWER™ TECHNOLOGY HELPS
• Independent Drawers = Variety of Loads
• An independent drawer-based dishwashing platform is part of what makes the DishDrawer™ dishwasher unique. In DishDrawer™ Double dishwashers, both drawers operate independently so different wash cycles can operate simultaneously to accomodate a variety of loads.
• SmartDrive™ Wash Mechanism = Better Dish Care
• The unique brushless DC motor acts as both a wash pump and a drain pump, which means fewer moving parts and greater reliability. The spray arm rotates at different speeds depending on the wash cycle selected, to deliver a superior clean and better dish care.
• Nine Wash Options = Comprehensive Washing
• The range of settings enables the dishwasher to wash everything from fine glass and crystal to heavily soiled pots and pans at the touch of a button.
• An independent drawer-based dishwashing platform is part of what makes the DishDrawer™ dishwasher unique. In DishDrawer™ Double dishwashers, both drawers operate independently so different wash cycles can operate simultaneously to accomodate a variety of loads.
• SmartDrive™ Wash Mechanism = Better Dish Care
• The unique brushless DC motor acts as both a wash pump and a drain pump, which means fewer moving parts and greater reliability. The spray arm rotates at different speeds depending on the wash cycle selected, to deliver a superior clean and better dish care.
• Nine Wash Options = Comprehensive Washing
• The range of settings enables the dishwasher to wash everything from fine glass and crystal to heavily soiled pots and pans at the touch of a button.
DISHDRAWER™ TECHNOLOGY
It combines compact technologies to provide a space efficient dishwasher in a drawer. The combination of the unique SmartDrive™ motor technology with intelligent electronics and simple mechanics means more space for dishes, greater reliability and better performance. The DishDrawer™ dishwasher's internal microprocessor controls how the wash mechanism operates based on the load and wash cycle. The spray arm rotates at different speeds depending on the wash cycle selected to deliver better dish care.
TRUE HALF LOAD
Each drawer holds a true half load for guilt-free small washes and fast turnaround of your dishes. Both drawers operate independently so different wash cycles can operate simultaneously to accommodate a variety of loads.
QUIET PERFORMER
Running at a very low decibel rate, these DishDrawer™ Dishwashers do their job without making a fuss. The combination of intelligent technology and simple mechanics means greater reliability and excellent wash performance.
EASY OF USE
DishDrawer™ Dishwashers are as easy to open and close as kitchen drawers and can be conveniently positioned at bench height for ease of loading and minimal bending. Flexible racking allows you to make adjustments to fit in a variety of dishes.
